Dell Q28-100G-CWDM4 Compatible 100GBASE-CWDM4 QSFP28 | FiberMall

Add to wish

Dell Q28-100G-CWDM4 Compatible 100G QSFP28 CWDM4 1310nm 2km LC SMF DDM Transceiver Module

Name: Dell Q28-100G-CWDM4 Compatible 100G QSFP28 CWDM4 1310nm 2km LC SMF DDM Transceiver Module
Brand: fibermall
SKU: 10027
Price: 110.00 USD
Availability: OutOfStock
Rating: 4.7 (13 reviews)

: Dell Q28-100G-CWDM4 Compatible 100G QSFP28 CWDM4 1310nm 2km LC SMF DDM Transceiver Module

13 Reviews

$110.00
In Stock

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

13 Reviews

SKU:10027

$ 110.00

Compatible: Cisco; FiberMall; Arista Networks; Brocade; DELL; EdgeCore; H3C; HPE (Aruba); HPE (H3C); Huawei; Juniper Networks; Mellanox; Palo Alto Networks

Transceiver Type: Q28-100G-ESR4; Q28-100G-SR4; Q28-100G-CWDM4; Q28-100G-PSM4-IR; Q28-100G-4WDM-10; Q28-100G-SR1.2; Q28-100G-LR4; Q28-100G-SWDM4; Q28-100G-BIDI; Q28-100G-BIDI-ON; Q28-100G-ER4-lite

FM PN:

QSFP28-100G-IR4

Ship From:

Asia

Shipping:

$ 28.20

to United States Via DHL

Estimated delivery time : 3-5 working days. See details

Quantity:

Total Price:

$ 110.00

Bulk Quote
Shipping & Returns

Bulk Quote
Shipping & Returns

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

Dell Q28-100G-CWDM4 Compatible 100G QSFP28 CWDM4 Transceiver Module (1271nm, 1291nm, 1311nm, 1331nm SMF 2km LC DDM)

The 100G QSFP28 CWDM4 transceiver modules are designed for 100 Gb Ethernet links over single-mode fiber up to 2 km. It complies with the 1000GBASE CWDM4 MSA standard. The module converts 25Gb/s electrical data from 4 input channels (ch) into 4 CWDM optical signals and multiplexes them into a single channel for 100Gb/s optical transmission. The central wavelengths of the 4 CWDM channels are 1271, 1291, 1311, and 1331 nm as members of the CWDM wavelength grid defined in ITU-T G.694.2.

Product Details

Dell Compatible	Q28-100G-CWDM4	Vendor Name	FiberMall
Form Factor	QSFP28	Max Data Rate	103.1Gbps
Wavelength	1271nm, 1291nm 1311nm, 1331nm	Max Distance	2km
Connector	Duplex LC	Transmitter Type	CWDM DFB
Cable Type	SMF	Receiver Type	PIN
TX Power	-6.5~+2.5dBm	Receiver Sensitivity	< -11.5dBm
Protocols	100G Ethernet, MSA Compliant	Operation Temperature	0 to 70°C (32 to 158°F)

Quality Assurance

Excellent quality is the foundation of FiberMall's survival and development. Our operation team are experts with many years' experience in the optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certifications, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

: Keep In Stock; Fast Delivery

: Professional Service; Technical Support

: Worry-Free Guarantee; Shopping Satisfactorily

: Premium Quality; High stability

Rigorous Industrial ProductTesting

Optical communication products are industrial products that require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials, and production technology to ensure the first-class quality of our products so that your project can be used, installed stably, and reliably

: Temperature Impact; High and low-temperature cycle, aging test to ensure good temperature characteristics

: Mechanical Impact; Mechanical vibration testing to ensure the stability of products

: EMI Testing; Excellent design and rigorous testing ensure good EMI performance

: MTBF Testing; MTBF(Mean Time Between Failures)testing ensures high stability

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices. Before shipment, We will code the optical modules or DAC/AOC cables, and then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

: Coding(EEPROM Programming)

: Testing system

Partial test demonstartion

ARISTA 7060SX2-48YC6

H3C S6850-56HF

Cisco N9K-C92160YC-X

HP JG510A

Juniper QFX5110-48S-AFO

Mellanox SN4700

Cisco-N9K-C93600CD-GX

NVIDIA QM9790

Ruijie RG-S6990-128QC2XS

	QSFP28-100G-IR4	QSFP28-100G-FR1
Dell Compatible	Q28-100G-CWDM4	Q28-100G-FR
Vendor Name	FiberMall	FiberMall
Form Factor	QSFP28	QSFP28
Max Data Rate	103.1Gbps	100Gbps Single Lambda
Wavelength	1271nm, 1291nm 1311nm, 1331nm	1310nm
Max Distance	2km	2km
Connector	Duplex LC	Duplex LC
Transmitter Type	CWDM DFB	EML
Cable Type	SMF	SMF
Receiver Type	PIN	PIN
TX Power	-6.5~+2.5dBm	-2.4~+4.0dBm
Receiver Sensitivity	< -11.5dBm	< -4.5dBm
Protocols	100G Ethernet, MSA Compliant	100G Lambda MSA 100G-FR, 100G Ethernet
Operation Temperature	0 to 70°C (32 to 158°F)	0 to 70°C (32 to 158°F)
