| FiberMall P/N | QSFP28-100G-IR4 | Vendor Name | FiberMall |
| Form Factor | QSFP28 | Max Data Rate | 103.1Gbps |
| Wavelength | 1271nm, 1291nm 1311nm, 1331nm | Max Distance | 2km |
| Connector | Duplex LC | Transmitter Type | CWDM DFB |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -6.5~+2.5dBm | Receiver Sensitivity | < -11.5dBm |
| Protocols | 100G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
|
FiberMall P/N
|
QSFP28-100G-FR1
|
QSFP28-100G-IR4
|
|
Vendor Name
|
FiberMall
|
FiberMall
|
|
Form Factor
|
QSFP28
|
QSFP28
|
|
Max Data Rate
|
100Gbps Single Lambda
|
103.1Gbps
|
|
Wavelength
|
1310nm
|
1271nm, 1291nm
1311nm, 1331nm |
|
Max Distance
|
2km
|
2km
|
|
Connector
|
Duplex LC
|
Duplex LC
|
|
Transmitter Type
|
EML
|
CWDM DFB
|
|
Cable Type
|
SMF
|
SMF
|
|
Receiver Type
|
PIN
|
PIN
|
|
TX Power
|
-2.4~+4.0dBm
|
-6.5~+2.5dBm
|
|
Receiver Sensitivity
|
< -4.5dBm
|
< -11.5dBm
|
|
DDM Support
|
YES
|
-
|
|
FEC Support
|
YES
|
-
|
|
Protocols
|
100G Lambda MSA 100G-FR, 100G Ethernet
|
100G Ethernet, MSA Compliant
|
|
Operation Temperature
|
0 to 70°C (32 to 158°F)
|
0 to 70°C (32 to 158°F)
|
Product Features
v Single +3.3V power supply
v QSFP28 MSA package with duplex LC connector
v Supports103.1Gb/s, each lane bit rate 25.78 Gb/s
v 4 CWDM lanes MUX/DEMUX design
v Up to 2km transmission on single mode fiber (SMF) with FEC
v CWDM DFB laser and PIN receiver
v Maximum power consumption 3.5W
v Supports Data Center Interconnect, 100GBASE-SR4 100G Ethernet, Infiniband QDR, and DDR interconnects
