{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| FiberMall P/N | XGSPON-ONU-C | Vendor Name | FiberMall |
| Application | XGSPON ONU | ODN Class | N1/N2 |
| Wavelength | TX 1270nm/RX 1577nm | Data Rate | TX 9.95G/RX 9.95G |
| TX Power | +4.0~+9.0dBm | Receiver Sensitivity | < -28.0dBm |
| Package | SFP+ | Interface | SC |
| Cable Type | SMF | Max Distance | 20km |
| Operation Temperature | 0 to 70°C (32 to 158°F) | Protocols | ITU-T G.9807, SFP+ MSA |
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices. Before shipment, We will code the optical modules or DAC/AOC cables, then test them on the corresponding switches to ensure that our products are 100% compatible with your system. |
Product Features
v Single fiber bi-directional data links asymmetric TX 9.953Gbps/RX9.953Gbps application
v 0 to 70°C operating case temperature
v Single 3.3V power supply
v SFP+ package with SC/UPC Receptacle connector
v Hot-pluggable capability
v High power 1270nm DML DFB LD and high sensitivity 1577nm APD
v Support 20km transmission distance with SMF
v CML compatible data input/output interface
v Low power dissipation
v Low EMI and excellent ESD protection
v Digital diagnostic monitor interface
v RoHS-6 compliance
Applications
v 10-Gigabit-capable passive optical networks
Standards
v Complies with SFP+ MSA (SFF-8431)
v Complies with ITU-T G.9807
v Complies with SFF-8472
v Complies with FCC 47 CFR Part 15, Class B
v Complies with FDA 21 CFR 1040.10 and 1040.11, ClassⅠ
v Complies with FDA 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007
Q: Does this support changing the OMCI version, ONU Hardware version, Software Version, and Vendor strings? By A***y on 2022-07-18
A: Sorry, it doesn't supportBy CHEN YIFEN on 2022-07-20
