Juniper CFP2-100G-SR10-D3 Compatible 100GE SR10 CFP2 transceiver modules are designed for use in 100 Gigabit Ethernet links and 10x11.2G OTN client interfaces over multimode fiber. They are compliant with the CFP2 MSA and with IEEE 802.3ba 100GBASE-SR10. Digital diagnostics functions are available via the MDIO interface.
| Juniper Compatible | CFP2-100G-SR10-D3 | Vendor Name | FiberMall |
| Form Factor | CFP2 | Max Data Rate | 103.1Gbps |
| Wavelength | 850nm | Max Distance | 100m on OM3 / 150m on OM4 |
| Connector | MTP/MPO-24 | Transmitter Type | VCSEL |
| Cable Type | MMF | Receiver Type | PIN |
| TX Power | -8.0~+1.0dBm | Receiver Sensitivity | < -9.9dBm |
| Protocols | 100G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
Product Features
v Supports 103.1Gb/s to 112Gb/s bit rates
v MPO 24 receptacle optical interface
v CPPI electrical interface
v Uncooled 10x10Gb/s 850nm transmitter
v 10 parallel electrical serial interface
v Applicable for 100m with OM3 MMF and 150m with OM4 MMF
v Low power consumption <4W
v Compliant with 100GBASE-SR10
v Application for 100GBASE-SR10 Ethernet, 10x11.2Gb/s Multimode, 10x 10GE-SRLite Ethernet
