TP-Link XGSPON ONU Stick SFP+ with MAC Address Module | FiberMall

Add to wish

TP-Link Compatible XGSPON ONU Stick with WAS-110 SFP+ TX-9.95G/RX-9.95G TX-1270nm/RX-1577nm SC/APC DDM Optical Transceivers

Name: TP-Link Compatible XGSPON ONU Stick with WAS-110 SFP+ TX-9.95G/RX-9.95G TX-1270nm/RX-1577nm SC/APC DDM Optical Transceivers
Brand: fibermall
SKU: 20860
Price: 160.00 USD
Availability: OutOfStock
Rating: 5 (13 reviews)

: TP-Link Compatible XGSPON ONU Stick with WAS-110 SFP+ TX-9.95G/RX-9.95G TX-1270nm/RX-1577nm SC/APC DDM Optical Transceivers

13 Reviews

$ 160.00
In Stock

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

13 Reviews

SKU:20860

$ 160.00

Compatible: Cisco; FiberMall; Aruba; H3C; Huawei; Intel; Mellanox; MikroTik; Netgate; TP-Link; Ubiquiti

Firmware Version: Standard; 8311 Community

FM PN:

XGSPON-ONU-STICK

Ship From:

Asia

Shipping:

$ 29.66

to United States Via DHL

Estimated delivery time : 3-5 working days. See details

Quantity:

Total Price:

$ 160.00

Bulk Quote
Shipping & Returns

Bulk Quote
Shipping & Returns

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

TP-Link Compatible XGSPON ONU Stick with MAC Class N1/N2 Transceiver Chipset: MaxLinear PRX126 (SMF, 1270nm-TX/1577nm-RX, 20km, SC/APC, DDM)

The XGSPON ONU stick with MAC module is designed for 10G passive optical network systems. The STICK optical module can fully meet the requirements of the carrier-grade FTTB\ FTTH\ FTTO device. It can be hot-swapped into the SFP+ slot of the Layer 2 Ethernet switch. The whole machine can be used as an ONT or even an MDU so that the entire device can be directly connected to the XGSPON optical network; the central office OLT only needs to register the XGSPON ONU STICK optical module as if it were a typical optical CAT. The communication device can complete the access switch from the original P2P.

Product Details

TP-Link Compatible	XGSPON-ONU-STICK	Vendor Name	FiberMall
Application	XGSPON ONU	ODN Class	N1/N2
Wavelength	TX 1270nm/RX 1577nm	Data Rate	TX 9.95G/RX 9.95G
TX Power	+4.0~+9.0dBm	Receiver Sensitivity	< -28.5dBm
Package	SFP+	Interface	SC/APC
Cable Type	SMF	Max Distance	20km
Operation Temperature	-20°C~85℃	Protocols	ITU-T G.9807, SFP+ MSA

Quality Assurance

Excellent quality is the foundation of FiberMall's survival and development. Our operations team is made up of experts with many years of experience in the optical communication industry. Our manufacturers are first-class in the industry. Many of them are qualified OEMs for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process, production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certifications, such as ISO 9001, CE, RoHS, FCC, etc.

To access the XGSPON STICK ONU Standard firmware web interface: Set your computer's IP address to the same subnet as 192.168.11.X (e.g., 192.168.11.2). Enter 192.168.11.1 in your browser’s address bar to open the login page.

Menu Path: Status → Device: View device model, SN, firmware version, and data statistics.

For detailed operation instructions, please refer to the XGSPON Stick ONU Standard Firmware Web Interface Guide.

This FTTH diagram illustrates an XGSPON network: The Central Office routes signals via Optical Splitters to NAPs (Network Access Points), distributing symmetrical 10G bandwidth to Business hubs and Dwelling Units, then Homes. Blue/white design clarifies fiber paths, highlighting efficient XGSPON-based FTTH infrastructure for high-speed connectivity.

	XGSPON-ONU-STICK	XGSPON-ONU-C	GPON-ONU-STB+
FiberMall P/N	XGSPON-ONU-STICK	XGSPON-ONU-C	GPON-ONU-STB+
Vendor Name	FiberMall	FiberMall	FiberMall
Application	XGSPON ONU	XGSPON ONU	-
ODN Class	N1/N2	N1/N2	-
Wavelength	TX 1270nm/RX 1577nm	TX 1270nm/RX 1577nm	TX-1310nm/RX-1490nm
Data Rate	TX 9.95G/RX 9.95G	TX 9.95G/RX 9.95G	-
TX Power	+4.0~+9.0dBm	+4.0~+9.0dBm	+0.5~+5.0dBm
Receiver Sensitivity	< -28.5dBm	< -28.0dBm	< -28.0dBm
Package	SFP+	SFP+	-
Interface	SC/APC	SC	-
Cable Type	SMF	SMF	SMF
Max Distance	20km	20km	20km
Operation Temperature	-20°C~85℃	0 to 70°C (32 to 158°F)	0 to 70°C (32 to 158°F)
Protocols	ITU-T G.9807, SFP+ MSA	ITU-T G.9807, SFP+ MSA	MSA and IEEE 802.3

Resources

Datasheet

Related Info

Questions & Answers
Ask a Question

No data

Customer Reviews
Write a Review

5

13 reviews
5 Stars

100%

4 Stars

0%

3 Stars

0%

2 Stars

0%

1 Star

0%

All Reviews (13)

All Reviews

5 stars only

4 stars only

3 stars only

2 stars only

1 star only
Reviews with Pictures ( 4 )
See All Reviews

Joshua White

Verified Purchase

5.0

2025-03-07

Successfully used on the AT&T network—manual configuration bypasses the original optical modem, and the community firmware's compatibility exceeds expectations.

2 Helpful vote Comments

Robert Williams

Verified Purchase

5.0

2025-02-27

Fast delivery, works great. Perfectly compatible with our existing equipment. The DDM function facilitates monitoring and maintenance.

3 Helpful vote Comments

Tariq Rashid

Verified Purchase

5.0

2025-02-03

What's great about this XGS-PON ONU is that it pairs flawlessly with our legacy GPON OLT, saving us the hassle of infrastructure overhaul.

16 Helpful vote Comments

Sophia Donovan

Verified Purchase

5.0

2024-12-03

Customer service replies are very prompt, and the service is excellent.

6 Helpful vote Comments

Lucas

Verified Purchase

5.0

2024-11-10

The price is reasonable with outstanding performance. The seller's service was highly professional, and the purchasing process went seamlessly.

7 Helpful vote Comments

Orla

Verified Purchase

5.0

2024-10-27

Stable and reliable data transmission, ideal for FTTH networks.

9 Helpful vote Comments

Alicia Wood

Verified Purchase

5.0

2024-10-13

I used it to upgrade my network, and it was delivered quickly after I placed the order. The packaging was also perfect.

14 Helpful vote Comments

Olivia

Verified Purchase

5.0

2024-09-20

Fibermall team is very professional and patient, answering many of my questions. Thank you very much.

2 Helpful vote Comments

Patrick Ward

Verified Purchase

5.0

2024-09-13

I saw a video on YouTube that shows how to use an Stick SFP+ module to connect the fiber optic line directly from AT&T into our router, achieving a true bypass. So, I placed an order. It was very useful after trying it out. That's great!

6 Helpful vote Comments

Dmitry Petrov

Verified Purchase

5.0

2024-08-09

Received the product in pristine condition - the module looks brand new with zero defects.

4 Helpful vote Comments
