| AVAGO Broadcom Compatible | AFCT-89SDDZ | Vendor Name | FiberMall |
| Form Factor | QSFP28 | Max Data Rate | 100Gbps Single Lambda |
| Wavelength | 1310nm | Max Distance | 500m |
| Connector | Duplex LC | Transmitter Type | EML |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -2.4~+4.0dBm | Receiver Sensitivity | < -4.4dBm |
| DDM Support | YES | FEC Support | YES |
| Protocols | IEEE802.3cd 100GBASE-DR, 100G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
|
AVAGO Broadcom Compatible
|
AFCT-89SFDZ
|
AFCT-89SDDZ
|
|
Vendor Name
|
FiberMall
|
FiberMall
|
|
Form Factor
|
QSFP28
|
QSFP28
|
|
Max Data Rate
|
100Gbps Single Lambda
|
100Gbps Single Lambda
|
|
Wavelength
|
1310nm
|
1310nm
|
|
Max Distance
|
2km
|
500m
|
|
Connector
|
Duplex LC
|
Duplex LC
|
|
Transmitter Type
|
EML
|
EML
|
|
Cable Type
|
SMF
|
SMF
|
|
Receiver Type
|
PIN
|
PIN
|
|
TX Power
|
-2.4~+4.0dBm
|
-2.4~+4.0dBm
|
|
Receiver Sensitivity
|
< -4.5dBm
|
< -4.4dBm
|
|
DDM Support
|
YES
|
YES
|
|
FEC Support
|
YES
|
YES
|
|
Protocols
|
100G Lambda MSA 100G-FR, 100G Ethernet
|
IEEE802.3cd 100GBASE-DR, 100G Ethernet, MSA Compliant
|
|
Operation Temperature
|
0 to 70°C (32 to 158°F)
|
0 to 70°C (32 to 158°F)
|
Product Features
v Single +3.3V power supply
v QSFP28 MSA package with LC connector
v Supports 53.125Gbaud
v IEEE802.3cd 100GBASE-DR Specification compliant
v Up to 500m transmission on single mode fiber (SMF) with FEC
v 4x25G electrical interface (OIF CEI-28G- VSR)
v Maximum power consumption 4W
v Supports Data Center Interconnect, 100G Ethernet, and Enterprise networking.
