15m 2x200G QSFP56 to 2x200G QSFP56 Breakout AOC Cable | FiberMall

Add to wish

2QSFP56-200G-AOC-15M 15m (49ft) 2x200G QSFP56 to 2x200G QSFP56 PAM4 Breakout Active Optical Cable

Name: 2QSFP56-200G-AOC-15M 15m (49ft) 2x200G QSFP56 to 2x200G QSFP56 PAM4 Breakout Active Optical Cable
Brand: fibermall
SKU: 19221
Price: 830.00 USD
Availability: OutOfStock
Rating: 5 (1 reviews)

: {{detail_data.prodInfo.name}}

{{comment.count}} Reviews

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }}
{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

{{comment.count}} Reviews

SKU:19221

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }} {{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}

Compatible: FiberMall

Length: 3m; 3m (10ft); 5m; 5m (16ft); 7m; 10m; 10m (33ft); 15m; 15m (49ft); 20m; 20m (66ft); 30m; 30m (98ft)

FM PN:

2QSFP56-200G-AOC-15M

Ship From:

Asia

Shipping:

Free Shipping

Can't deliver

to Canada Via {{now_chooseship?now_chooseship.name:''}}

Available for back order. See details

Quantity:

( Min. Order {{detail_data.prodInfo.minimum_ordered_quantity}} )

Total Price:

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_total_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}

Bulk Quote
Shipping & Returns

Bulk Quote
Shipping & Returns

Add to wish ( {{detail_data.wish_value}} Adds)

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

15m 2x200G QSFP56 to 2x200G QSFP56 Breakout Active Optical Cable (QSFP56 to QSFP56 AOC Breakout Cable, Active 15m)

Product Details

FiberMall P/N	2QSFP56-200G-AOC-15M	Vendor Name	FiberMall
Form Factor	2x QSFP56 to 2x QSFP56	Max Data Rate	212.5Gb/s
Wavelength	850nm	Cable Length	15m (49ft)
Modulation Format	PAM4	Host Required	FEC
Jacket Material	LSZH	Minimum Bend Radius	30mm
Cable Type	MMF	DDM Support	Yes
Transmitter Type	850nm VCSEL	Receiver Type	PIN
Operating Case Temperature	0 to 70°C (32 to 158°F)	Voltage Supply	3.3V
Protocols	QSFP56 MSA, CMIS IEEE 802.3cd 200GBASE-SR4	Maximum Power	< 5W (200G QSFP56)
Connector	Fiber Optic Cable	Application	200GBASE-SR4, 200G InfiniBand HDR

Quality Assurance

Excellent quality is the foundation of FiberMall' s survival and development. Our operation team are experts with many years' experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

: Keep In Stock; Fast Delivery

: Professional Service; Technical Support

: Worry-Free Guarantee; Shopping Satisfactorily

: Premium Quality; High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

: Temperature Impact; High and low temperature cycle,aging test to ensure good temperature characteristics

: Mechanical Impact; Mechanicalvibration testing to ensure the stability of products

: EMI Testing; Excellent designand rigorous testing ensuregood EMI performance

: MTBF Testing; MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

: Coding(EEPROM Programming)

: Testing system

Partial test demonstartion

: Cisco N9k-C92160YC-X-C

: HP ProCurve 5406zl J8697A

: ARISTA 7-50QX-32

: Juniper EX4300

: HW S5700-28X-L1-AC

: Brocade VDX 6720

: DELL S4048 ON

: DATACOM DM4100

: H3C LS-5500-28C-S

Product Features

v Hot Pluggable QSFP Cable End

v Supports 212.5Gb/s aggregate bit rate

v Low Power Dissipation, Typ. 5.0W Each End

v 4x50G PAM4 VCSEL/PIN photo-detector

v Operating Case Temperature: 0ºC~70ºC

v SFF-8636 Management Interface

v SFF-8679: General Electrical

v IEEE 802.3cd: Physical Layer Specifications and Management Parameters

Applications

v Ethernet for 200GBASE-SR4

v 200G InfiniBand HDR

v ROHS-6: Environment Safety
