{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| FiberMall P/N | OSFP-2Q56-AOC20M | Vendor Name | FiberMall |
| Form Factor | OSFP to 2x QSFP56 | Max Data Rate | 400Gb/s to 2 x 200Gb/s |
| Wavelength | 850nm | Cable Length | 20m (65.6ft) |
| Modulation Format | PAM4 | Host Required | FEC |
| Jacket Material | LSZH | Minimum Bend Radius | 30mm |
| Cable Type | MMF | DDM Support | Yes |
| Transmitter Type | 850nm VCSEL | Receiver Type | PIN |
| Operating Case Temperature | 0 to 70°C (32 to 158°F) | Voltage Supply | 3.3V |
| Protocols | CMIS 4.0, SFF-8636 | Maximum Power | < 10W (400G OSFP) < 5W (200G QSFP56) |
| Connector | Fiber Optic Cable | Application | 400GBASE-SR8 to 2x 200GBASE HDR, Ethernet |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
