{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| FiberMall P/N | Q28-OD100G03-25C | Vendor Name | FiberMall |
| Form Factor | QSFP28 | Max Data Rate | 100Gbps |
| Wavelength | 1297.80nm | Max Distance | 25km |
| Connector | Duplex LC | Transmitter Type | EML |
| Cable Type | SMF | Receiver Type | APD |
| DDM Support | Yes | Modulation Format | PAM4 |
| TX Power | 0~+5.6dBm | Receiver Sensitivity | < -15.0dBm |
| Protocols | QSFP28 MSA, SFF-8636 | Operation Temperature | 0 to 70°C (32 to 158°F) |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
Product Features
v Single-lambda 100Gbps transmission
v O-band DWDM with 200GHz channel spacing
v Aligned to 800GHz spacing LAN-WDM grid
v Up to 25km over G.652 SMF
v Duplex LC connector
v PAM4 optical signal with integrated FEC
v 4x25.78Gbps CAUI-4 host interface
v Compliant with QSFP28 MSA SFF-8636
v QSFP28 MSA digital monitoring functions
v Safety Certification: TUV/UL/FDA*Note1
v RoHS Compliant
Applications
v 100GbE multiple channels transmissions using O-band DWDM wavelengths
