{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| FiberMall P/N | QSFP-DD-400G-AOC-60M | Vendor Name | FiberMall |
| Form Factor | QSFP112 | Max Data Rate | 425Gb/s |
| Wavelength | 850nm | Cable Length | 60m (197ft) |
| Modulation Format | PAM4 | Host Required | FEC |
| Number of Lanes | 8 TX and 8 RX (50G) | Voltage Supply | 3.3V |
| Cable Type | MMF | DDM Support | Yes |
| Transmitter Type | 850nm VCSEL | Receiver Type | PIN |
| Operating Case Temperature | 0 to 70°C (32 to 158°F) | Maximum Power | <8.0W Each End |
| Protocols | QSFP112 MSA Rev2.1.1 and IEEE 802.3db, IEEE 802.3ck | Application | 400G Ethernet and 200G Ethernet |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
Product Features
v QSFP112 Serial Optical Interface
v 4x100G PAM4 retimed 400GAUI-4 electrical interface
v 4 channel VCSEL arrays and 4 channels PIN photo detector arrays
v Maximum link length of 60m on OM3 or 100m on OM4
v QSFP112 MSA Compliant
v Compliant to QSFP112_MSA_Specification_Rev2.1.1
v Compliant with CMIS 5.2
v Compliant with IEEE 802.3db
v Compliant to IEEE 802.3ck
v Low Power Consumption
