H3C SFP-XG-LH80-SM1490-BIDI Compatible 10G BX SFP+ BIDI Transceiver Module (TX1490nm/RX1550nm SMF 80km LC DDM)

H3C SFP-XG-LH80-SM1490-BIDI Compatible 10G BX SFP+ BIDI transceiver supports up to 80km over OS2 SMF via an LC simplex connector. This transceiver is compliant with SFF-8431 and IEEE 802.3ae standards. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. It Supports 1550nm EML and 1490nm APD into an LC connector, which allows an 80km link distance over single-mode fiber.

Product Details

H3C Compatible	SFP-XG-LH80-SM1490-BIDI	Vendor Name	FiberMall
Form Factor	SFP+	Max Data Rate	10.7Gbps
Wavelength	TX1490nm/RX1550nm	Max Distance	80km
Connector	Simplex LC	Transmitter Type	1490nm EML
Cable Type	SMF	Receiver Type	APD
TX Power	0~+4.0dBm	Receiver Sensitivity	< -22.0dBm
Protocols	10G Ethernet, MSA Compliant	Operation Temperature	0 to 70°C (32 to 158°F)

Quality Assurance

Excellent quality is the foundation of FiberMall' s survival and development. Our operation team are experts with many years' experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

: Keep In Stock; Fast Delivery

: Professional Service; Technical Support

: Worry-Free Guarantee; Shopping Satisfactorily

: Premium Quality; High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

: Temperature Impact; High and low temperature cycle,aging test to ensure good temperature characteristics

: Mechanical Impact; Mechanicalvibration testing to ensure the stability of products

: EMI Testing; Excellent designand rigorous testing ensuregood EMI performance

: MTBF Testing; MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

: Coding(EEPROM Programming)

: Testing system

Partial test demonstartion

: Cisco N9k-C92160YC-X-C

: HP ProCurve 5406zl J8697A

: ARISTA 7-50QX-32

: Juniper EX4300

: HW S5700-28X-L1-AC

: Brocade VDX 6720

: DELL S4048 ON

: DATACOM DM4100

: H3C LS-5500-28C-S

10G BIDI SFP

Product Features

v Supports up to 10.7Gbps bit rates

v Hot-pluggable SFP+ footprint

v 1490nm Cooled EML laser and APD photodiode, Up to 80km for SMF transmission

v Compliant with SFP+ MSA and SFF-8472 with simplex LC receptacle

v Compatible with RoHS

v Single +3.3V power supply

v Real-Time Digital Diagnostic Monitoring

v Application for 10Gbps Optical systems, 10GBASE-ZR at 10.3125Gbps, 10GBASE-ZW at 9.953Gbps
