{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| Mellanox Compatible | MFS1S00-V100E | Vendor Name | FiberMall |
| Form Factor | QSFP56 | Max Data Rate | 212.5Gb/s |
| Wavelength | 850nm | Cable Length | 100m (328.0ft) |
| Modulation Format | DSP/PAM4 | Host Required | FEC |
| Connector | Fiber Optic Cable | Voltage Supply | 3.3V |
| Cable Type | MMF | DDM Support | Yes |
| Transmitter Type | 850nm VCSEL | Receiver Type | PIN |
| Operating Case Temperature | 0 to 70°C (32 to 158°F) | Maximum Power | <5.0W |
| Protocols | SFF-8636 and SFF-8679, IEEE 802.3cd | Application | Ethernet for 200GBASE-SR4 |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
Product Features
v Hot Pluggable QSFP Cable End
v Supports 212.5Gb/s aggregate bit rate
v Low Power Dissipation, Typ. 5.0W Each End
v 4x50G PAM4 VCSEL/PIN photodetector
v Operating Case Temperature: 0℃~70
v SFF-8636 Management Interface
v SFF-8679: General Electrical
v IEEE 802.3cd: Physical Layer Specifications and Management Parameters
v ROHS-6: Environment Safety
Applications
v Ethernet for 200GBASE-SR4
