Mellanox MMA2L20-CW33-10 Compatible 25G CWDM SFP28 Transceiver Module (1330nm SMF 10km LC DDM)
This SFP28 transceiver provides 25GBase-CWDM throughput up to 10km over single-mode fiber (SMF) using a wavelength of 1330nm via an LC duplex connector. It provides a 25GBASE Ethernet connectivity option for 25G Ethernet, telecom, and data centers. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.
Product Details
Mellanox Compatible | MMA2L20-CW33-10 | Vendor Name | FiberMall |
Form Factor | SFP28 | Max Data Rate | 25.78Gbps |
Wavelength | 1330nm | Max Distance | 10km |
Connector | Duplex LC | Transmitter Type | CWDM DFB |
Cable Type | SMF | Receiver Type | PIN |
TX Power | -4.0~+4.0dBm | Receiver Sensitivity | < -13.3dBm |
Protocols | MSA Compliant, 25GBASE Ethernet | Operation Temperature | 0 to 70°C (32 to 158°F) |
Quality
Assurance
Excellent quality is the foundation of FiberMall's survival and development. Our operation team are experts with many years' experience in the optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.
Quality Certification
We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certifications, such as ISO 9001, CE, RoHS, FCC, etc.
our advantages
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Keep In Stock
- Fast Delivery
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Professional Service
- Technical Support
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Worry-Free Guarantee
- Shopping Satisfactorily
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Premium Quality
- High stability
Rigorous Industrial ProductTesting
Optical communication products are industrial products that require high stability and
reliability.FIBERMALL adopts leading product design, first-class raw materials, and production
technology to ensure the first-class quality of our products so that your project can be used, installed
stably, and reliably
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Temperature Impact
- High and low-temperature cycle, aging test to ensure good temperature characteristics
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
Mechanical Impact
- Mechanical vibration testing to ensure the stability of products
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
EMI Testing
- Excellent design and rigorous testing ensure good EMI performance
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
MTBF Testing
- MTBF(Mean Time Between Failures)testing ensures high stability
100% 3rd Party Compatible
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices. Before
shipment, We will code the optical modules or DAC/AOC cables, and then test them on the corresponding
switches to ensure that our products are 100% compatible with your system.
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
- Coding(EEPROM Programming)
![Mellanox MMA2L20-CW33-10 1330nm SFP28 CWDM Transceiver | FiberMall]()
- Testing system
Partial test demonstartion
-
ARISTA 7060SX2-48YC6
-
H3C S6850-56HF
-
Cisco N9K-C92160YC-X
-
HP JG510A
-
Juniper QFX5110-48S-AFO
-
Mellanox SN4700
-
Cisco-N9K-C93600CD-GX
-
NVIDIA QM9790
-
Ruijie RG-S6990-128QC2XS
