HPE H3C JD092A Compatible 10G SFP+ SR Module | FiberMall

Add to wish

HPE H3C JD092A Compatible 10G SFP+ SR 850nm 300m LC MMF DDM Transceiver Module

Name: HPE H3C JD092A Compatible 10G SFP+ SR 850nm 300m LC MMF DDM Transceiver Module
Brand: fibermall
SKU: 17164
Price: 12.00 USD
Availability: OutOfStock
Rating: 5 (8 reviews)

: {{detail_data.prodInfo.name}}

{{comment.count}} Reviews

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }}
{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

{{comment.count}} Reviews

SKU:17164

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.value }} {{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}

Compatible: Cisco; FiberMall; AVAGO (Broadcom); Alcatel-Lucent; Arista Networks; Avago; Avaya; Brocade; Ciena; Cisco (Meraki); D-Link; DELL; EdgeCore; Extreme; F5 Networks; H3C; HPE (Aruba); HPE (BladeSystem); HPE (H3C); HPE (Intel); HPE (Procurve); Huawei; IBM; Intel; Juniper; Mellanox; MikroTik; Netgear; Palo Alto Networks; Ruijie; Ubiquiti; ZTE

Transceiver Type: JD092A; JD092B; JD093A; JD093B; JD094A; JD094B; JG234A; SFP-10G-ZR

FM PN:

SFP-10G85-SR

Ship From:

Asia

Shipping:

Free Shipping

Can't deliver

to United States Via {{now_chooseship?now_chooseship.name:''}}

Estimated delivery time : 3-5 working days. See details

Quantity:

( Min. Order {{detail_data.prodInfo.minimum_ordered_quantity}} )

Total Price:

{{ detail_data.displayed_price.unit_prefix }} {{ detail_data.displayed_price.original_total_price }} ({{ detail_data.displayed_price.rate_of_discount }}% OFF) {{detail_data.displayed_price.ex_sell_type}}

Bulk Quote
Shipping & Returns

Bulk Quote
Shipping & Returns

Add to wish ( {{detail_data.wish_value}} Adds)

Description
Specification
Matching Products
Resources
Q&A
Customer Reviews

HPE H3C JD092A Compatible 10G SFP+ SR Transceiver Module(850nm MMF 300m LC DDM)

HPE H3C JD092A Compatible 10G SFP+ SR transceivers are high-performance, cost-effective modules supporting a data rate of 10.3 Gbps. The transceiver consists of three sections: a VCSEL laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA), and an MCU control unit. All modules satisfy class I laser safety requirements. The transceivers are compatible with SFP Multi-Source Agreement and SFF-8472 digital diagnostics functions.

Product Details

HPE Compatible	JD092A	Vendor Name	FiberMall
Form Factor	SFP+	Max Data Rate	10.7Gbps
Wavelength	850nm	Max Distance	300m on OM3
Connector	Duplex LC	Transmitter Type	VCSEL 850nm
Cable Type	MMF	Receiver Type	PIN
TX Power	-6.5~-0.5dBm	Receiver Sensitivity	< -10.5dBm
Protocols	10G Ethernet, MSA Compliant	Operation Temperature	0 to 70°C (32 to 158°F)

Quality Assurance

Excellent quality is the foundation of FiberMall' s survival and development. Our operation team are experts with many years' experiences in optical communication industry. Our manufacturers are first-class manufacturers in the industry. Many of them have the qualification of OEM for first-class system equipment manufacturers.

Quality Certification

We control the quality of our products, including our strict qualification of manufacturers, quality control process and production technology, and compliance with certification and safety standards. At present, our products meet the industry standards and mainstream quality certification, such as ISO 9001, CE, RoHS, FCC, etc.

our advantages

: Keep In Stock; Fast Delivery

: Professional Service; Technical Support

: Worry-Free Guarantee; Shopping Satisfactorily

: Premium Quality; High stability

Rigorous Industrial ProductTesting

Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably

: Temperature Impact; High and low temperature cycle,aging test to ensure good temperature characteristics

: Mechanical Impact; Mechanicalvibration testing to ensure the stability of products

: EMI Testing; Excellent designand rigorous testing ensuregood EMI performance

: MTBF Testing; MTBF(Mean Time between Failures)testing ensure high stablility

100% 3rd Party Compatible

FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.

: Coding(EEPROM Programming)

: Testing system

Partial test demonstartion

: Cisco N9k-C92160YC-X-C

: HP ProCurve 5406zl J8697A

: ARISTA 7-50QX-32

: Juniper EX4300

: HW S5700-28X-L1-AC

: Brocade VDX 6720

: DELL S4048 ON

: DATACOM DM4100

: H3C LS-5500-28C-S

Product Features

v Supports up to 10.7Gbps bit rates

v Hot-pluggable SFP+ footprint

v 850nm VCSEL laser and PIN photodiode, Up to 300m for OM3-MMF transmission

v Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle

v Compatible with RoHS

v Single +3.3V power supply

v Real-Time Digital Diagnostic MonitoringFiber Optic Module

v Operating case temperature:

Standard: 0 to +70°C

Industrial: -40 to +85°C

v Application for 10GBASE-SR at 10.3125Gbps, 10GBASE-SW at 9.953Gbps

Matching Products

Pictures

ID#

Description

Price

Stock

Add to Cart

Resources

Datasheet

Related Info

Questions & Answers
Ask a Question

No data

Customer Reviews
Write a Review

{{stardata.star}}

{{comment.count}} reviews
5 Stars

{{comment.star5}}%

4 Stars

{{comment.star4}}%

3 Stars

{{comment.star3}}%

2 Stars

{{comment.star2}}%

1 Star

{{comment.star1}}%

All Reviews ({{comment.star_num?comment.star_num:comment.count}})

All Reviews

5 stars only

4 stars only

3 stars only

2 stars only

1 star only
Reviews with Pictures ( {{comment.pic_comment}} )
See All Reviews

No data

Henry

Verified Purchase

5.0

2024-07-04

Installed into mikrotik switch without any issue.

3 Helpful vote Comments

John

Verified Purchase

5.0

2024-05-16

Excellent SFP module, great value.

2 Helpful vote Comments

Chelsea Martinez

Verified Purchase

5.0

2023-10-21

Fibermall's 10G SFP+ module is compatible with my Mikrotik switch. It was quickly detected once plugged in, and it works flawlessly.

4 Helpful vote Comments

Steven Morris

Verified Purchase

5.0

2023-08-05

Excellent perfomance, the SFP-10G85-SR modules work perfectly with my Juniper equipment.

6 Helpful vote Comments

Adam Campbell

Verified Purchase

5.0

2023-04-18

Fast delivery with a very nice packing.

3 Helpful vote Comments

Natalie Hughes

Verified Purchase

5.0

2023-03-06

Good service and qualitative products. Highly recommended.

4 Helpful vote Comments

Nicole Robinson

Verified Purchase

5.0

2022-09-27

I ordered four SFP+ modules and two LC fiber jumpers to upgrade the backbone network at home. They work great, everything works as expected.

5 Helpful vote Comments

Eric

Verified Purchase

5.0

2022-05-05

I have purchased Fibermall products several times before, they worked well without any visible issues. The prices are very affordable and quite good.

7 Helpful vote Comments
