{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| Operating Wavelength | 4 Channels 1470-1610nm | Channel Space | 20nm |
| Passband | ITU±6.5nm | Insertion Loss | ≤1.4dB |
| Directivity | ≥ 45dB | Return Loss | ≥45dB |
| Adjacent Channel Isolation | ≥ 30dB | Non-adjacent Channel Isolation | ≥ 40dB |
| Polarization Dependent Loss | ≤ 0.2dB | Polarization Mode Dispersion | ≤ 0.2ps |
| Maximum Optical Power | 500mW | Dimensions (HxWxD) | 8x35x55mm |
| Operating Temperature | -5°C～+70°C | Storage Temperature | -40°C～+85°C |
Short Lead time
Professional Service
Worry-Free Guarantee
Premium Quality
| Number of channels | 4 | 8 | 16 |
|---|---|---|---|
| Wavelength range | CWDM:1270nm to 1610nm DWDM:C Band, 100 GHZ or 50 GHZ |
||
| Insertion loss | < 1.5dB | < 2.5dB | < 3.5dB |
| Isolation ratio of adjacent channels | >30dB | >30dB | >30dB |
| Isolation ratio of non-adjacent channels | >40dB | >40dB | >40dB |
| Return loss | >45dB | >45dB | >45dB |
| Direction | >50dB | >50dB | >50dB |
| Interface type | All interfaces are LC type | ||
| Work temperature | -40〜85℃ | ||
| Storage temperature | -40〜85℃ | ||
