{{parseInt(detail_data.left_num) ? 'In Stock' :detail_data.zeroStockOrder==0?'Out of Stock':'Available'}}
| Mellanox Compatible | MMA1L10-CR | Vendor Name | FiberMall |
| Form Factor | QSFP28 | Max Data Rate | 103.1Gbps |
| Wavelength | 1295.56nm, 1300.05nm 1304.58nm, 1309.14nm | Max Distance | 10km |
| Connector | Duplex LC | Transmitter Type | LAN WDM DFB |
| Cable Type | SMF | Receiver Type | PIN |
| TX Power | -4.3~+4.5dBm | Receiver Sensitivity | < -10.6dBm |
| Protocols | 100G Ethernet, MSA Compliant | Operation Temperature | 0 to 70°C (32 to 158°F) |
Keep In Stock
Professional Service
Worry-Free Guarantee
Premium Quality
Optical communication products belong to industrial products,which require high stability and reliability.FIBERMALL adopts leading product design, first-class raw materials and production technology to ensure the first-class quality of our products, so that your project can be used, installed stably and reliably
Temperature Impact
Mechanical Impact
EMI Testing
MTBF Testing
FiberMall Compatibility Testing Center has most of the mainstream brand switches and devices.Before shipment,We will code the optical modules or DAC/AOC cables,then test them on the corresponding switches to ensure that our products are 100% compatible with your system.
Product Features
v Single +3.3V power supply
v Supports 103.1Gb/s, each lane bit rate 25.78 Gb/s
v LAN WDM DFB laser and PIN receiver
v Up to 10km transmission on SMF
v QSFP28 MSA package with duplex LC connector
v Maximum power consumption 4W
v Complies with EU Directive 2011/65/EU (RoHS 6/6)
v Supports Data Center Interconnect, 100GBASE-LR4 100G Ethernet.
